-48% Digital Meter Battery Tester LCD Green Backlight Indicator Battery Capacity Monitor Panel Meter for 12V lead-acid battery etc

Ask Question

It is a Digital Meter/Battery Capacity Tester, Working voltage(conventional): DC 8~63V, Suitable for Lithium and lead-acid batteries, Applications: Various instruments and meters; portable device; power bank; medical device, electromobile, self-balance car or other products Voltage Capacity measurement.

Parameters:
  • Working voltage(conventional): DC 8~63V
  • Working voltage(low): DC 5~12V
  • Working power consumption: Max 5mA
  • Standby power consumption: Max 120μA
  • Sleep power consumption: Max 20uA
  • Voltage accuracy: ±1.0 %
  • Using ambient temperature range : 10~40°c
Instruction: ( Item Instruction will be send via email in PDF after received your order.)
  • 1, Power off the indicator
  • 2, Press and hold Kdn key
  • 3, Power on the indicator
  • 4, Release Kdn key,then the screen will display "Pbx" or "Lix" (Pb is lead-acid; Li is lithium battery; X is the number of cells),then use ↑ Kup and ↓ Kdn to select battery types.
  • Pb1: Pb12V lead-acid battery
  • Pb2: Pb24V lead-acid battery
  • Pb3: Pb36V lead-acid battery
  • Pb4: Pb48V lead-acid battery
  • Li2: 2 pcs lithium batteries
  • Li3: 3 pcs lithium batteries
  • ...
  • ...
  • Li9: 9 pcs lithium batteries
  • LiA: 10 pcs lithium batteries
  • Lib: 11 pcs lithium batteries
  • LiC: 12 pcs lithium batteries
  • Lid: 13 pcs lithium batteries
  • LiE: 14 pcs lithium batteries
  • LiF: 15 pcs lithium batteries
Package included:
  • 1 x Battery Capacity Tester (Battery Monitor )
