-47% 12W Power Supply Module, AC 85~264V DC 110~370V to DC12V 1A Switching Power Supply/Power Converter DC12V Adapter/Regulator/Driver

Ask Question

Parameters:


  • AC Voltage input: AC 85~264V
  • DC Voltage input: DC 110~370V
  • Frequency range: 47~63Hz
  • Input current: 0.5/115AC  0.25/230VDC
  • Surge current: cold start 10A/230V AC
  • Efficiency:78
  • Standby power consumption: ≤200mW/230VAC
  • Output voltage: DC 12V
  • Output voltage accuracy:±1%
  • Rated current: 1A
  • Rated power: 12W
  • Ripple and noise(rated input voltage):≤100mV
  • Linear adjustment rate(at full load): ±1%
  • Load adjustment rate: ±3%
  • Start and rise time(at full load): 2000ms, 30ms/115VAC  1000ms,30ms/230VAC
  • Hold time(at full load): 16ms/115VAC 50ms/230VAC
  • Overload protection (rated input voltage): 115%~150% of rated output power, protection mode: hiccup mode, it will automatically recover when the load gets normal again.
  • Short-circuit protection (rated input voltage): can be in short-circuit for a long time and will recover automatically
  • Over current protection (rated input voltage) : ≥1.1 times Io
  • Start-up delay time (Vin:230VAC): 500ms
  • Power-down hold time (Vin:230VAC) : 20ms
  • Working temperature: -30~70°c
  • Working humidity: 20~90%, no condensation
  • Temperature drift coefficient: ±0.02%/°c
  • Storage temperature and humidity: -40°c~+85°c 10~95%
  • Switch frequency: 20~67KHz


Product Features:


  • 1. Easy and convenient to install, you can choose H3.96~3A for AC input, VH3.96~2A for DC output, or 2.54 pins
  • 2. There are holes for fixing at the every corner that will protect from power down caused by moving and vibrating.
  • 3. Universally accepted input voltage: AC85~264V or DC 110~370V
  • 4. High efficiency, high power density, lower ripple and noise of output, high output voltage accuracy.
  • 5. High isolation between input and output; It has over current protection, short-circuit protection and temperature protection.
  • 6. Built in filter on output, no need to add filter circuit during using.


Package includes:


  • 1 x Switching Power Supply


Attributes
input voltage0.1V
output voltage12V

Write a review

Please login or register to review

12W Power Supply Module, AC 85~264V DC 110~370V to DC12V 1A Switching Power Supply/Power Converter DC12V Adapter/Regulator/Driver

  • Brand: Drok
  • Product Code: 2001710006
  • Availability: In Stock
  • $12.99
  • $6.85
  • Bulk Buy Discounts. Buy more please contact us
    Qty251030+
    Price$6.45$6.25$5.95$5.75
