-69% DC 12V 24V Voltage Tester DC3.3 ~ 30V Red/green LED Display Digital Voltmeter Waterproof Volt Panel Meter

Ask Question

It is a Red/green Digital Voltmeter DC 12V 24V Voltage Tester, Operating Voltage: DC3.3 ~ 30V , Display: 0.52" LED red/green, It has small size, high efficiency, long term stable and reliable quality,easy installation and use. Applications: suitable for most of electrical bike, motor and etc, will be a good tool to detect voltage.

Parameters:
  • Operating Voltage: DC3.3 ~ 30V
  • Operating Current: <20mA
  • Display: 0.52" LED red/green
  • Dimension: 54 L*30 W * 27H mm
  • Installing Size: 47.2*27.3
  • Testing Rate: >500mS/once
  • Testing Accuracy: 1%(±1 digit)
  • Protection for Reverse connection: yes


Extreme working conditions:
  • Minimum Operating Voltage: + 3.3V
  • Maximum Working Voltage: + 30V (The highest voltage can't be over 30V)
  • Working Temperature: -10 ~ + 65 ℃
  • Working Humidity: 10 to 80% (non-condensing)
  • Working Pressure: 80 ~ 106kPa
  • Sun Exposure: no direct exposure
Product Features:
  • Easy and convenient installation: two wires, just connect the red wire to the positive and connect the black wire to the negative.
  • Built in trimmer potentiometer, it is simple to do a calibration work.
  • Reverse connection protection, no worry it will burn your meter when get it connected reversely.
  • Wide application: suitable for most of electrical bike, motor and etc, will be a good tool to detect voltage.
Wiring Instructions:
  • Red wire: +
  • Black wire: -
Package Includes:
  • 1 x Waterproof Digital Voltmeter ( 2 Wires )
Attributes
output ways1

Write a review

Please login or register to review

DC 12V 24V Voltage Tester DC3.3 ~ 30V Red/green LED Display Digital Voltmeter Waterproof Volt Panel Meter

  • Brand: Drok
  • Product Code: 200196
  • Availability: In Stock
  • $13.50
  • $4.20
  • Bulk Buy Discounts. Buy more please contact us
    Qty5102030+
    Price$3.99$3.78$3.57$3.36
