It is a 5in1 USB Voltmeter/Ammeter/Power Meter/Capacity Tester/Charger, It has small size, high efficiency, long term stable and reliable quality,easy installation and use . Applications: Suitable for: most of mobile phones , mobile power , tablet PCs and other USB devices
- Input voltage: DC 3.20~15.0V
- Resolution: 0.01V (<10V); 0.1V(>/=10V)
- Measuring current: 0.00~3.00A(10A Max, but cannot work in 10A for long time)
- Resolution: 0.01A
- Capacitance measurement: 0~99999mA/H
- Capacitance: YES
- Capacitance accumulation: YES
- Power testing: 0.00~9.99~99.9W
- Over-voltage alarm: when voltage >/=5.6V, voltage digital point will flash quickly
- Lacking-voltage alarm: when voltage =4.4V, voltage digital point will flash slowly
- Over-current alarm: when current >/=3A, current digital point will flash quickly
- Short-circuit alarm: current digital point will flash quickly
Extreme working conditions:
- Working temperature: -10 °c~ +65 °c
- Operating Humidity: 10 ~ 80% (non-condensing)
- Working pressure: 80 ~ 106kPa
- Sun exposure: no direct exposure
OUTPUT I (Two Functions)
- 1. Support QC 2.0 charging (when OUT PUT I uses QC 2.0 charging, please do not insert any devices into the OUTPUT II)
- 2. Data communication function : mobile phones or other mobile devices for data transfer with a computer, and at the same time can view the voltage and current values.
- 3. Charging voltage output function: insert the Original Chargers can charge mobile phones or other mobile devices. The charging current is determined by compatibility.
- 1. Built-in intelligent charging control IC: match the most appropriate and safest current for your devices automatically. (mainly for Non-original Chargers, but also suitable for Original Chargers)
- 2. Charging voltage output function: universal-version, suitable for most of mobile phones , mobile power , tablet PCs and other USB devices.
- 3. Suitable for: most of mobile phones , mobile power , tablet PCs and other USB devices, such as BC1.2, YT/D1591-2009 and non-BC1.2 (including iPad, iPhone and Samsung Galaxy).
- 4. No data communication function
- 1 x USB Monitor
