Parameters:
- Input voltage: DC 8.0~48V (the input voltage must higher than output voltage at least 1V)
- Adjustable output voltage range: DC 3.3~24V
- Max output current: 3A
- Output power: max 36W
- Transfer efficiency: 90% (The efficiency is related to the input and output voltage, current and voltage difference.)
- Load regulation: S(I)≤0.8%
- Voltage regulation: S(u)≤0.8%
- Protective functions: Overheating protection, short-circuit protection, input reverse protection
Application:
- This module can be applied in the buck voltage field of the input voltage is higher than the output voltage, such as battery, power transformer, DIY adjustable regulated power supply, car power, industrial equipment step-down, it can convert 12 V to 3.3V, 12V to 5V, 24V to 5V, 12V, 24V, 36V to 24V, etc.
Package Includes:
- 1 x DC Buck Converter
