-58% Multifunction Digital Meter 4in1 Voltmeter/Ammeter/Power Meter/Energy Meter AC 80~260V/100A Digital Tester/Multimeter

Ask Question

It is a 4in1 Digital Meter/Multimeter, Working voltage: 80 ~ 260VAC, Rated power: 22kW, Operating frequency: 45~65Hz, It has small size, high efficiency, long term stable and reliable quality,easy installation and use, Applications:Suitable for industrial equipment,electronic equipment measurement or other products voltage/current /Power /Energy measurement.

Function:
  • Electrical parameter measurement function (voltage, current, active power, energy)
  • Overload alarm function (over power alarm threshold, backlight and power flashing to alarm).
  • Power alarm threshold preset function (can set power alarm threshold).
  • Reset energy function.
  • Store data when power off.
  • STN whole viewing angle LCD (display voltage, current, active power/energy at the same time)
  • Backlight function.
Parameters:
  • Working voltage: 80 ~ 260VAC
  • Test voltage: 80 ~ 260VAC
  • Rated power: 22kW
  • Operating frequency: 45~65Hz
  • Measurement accuracy: 1.0 grade
Display format:
  • Power: test range 0~22kW
    • within 1KW, the display format is 0.0~999.9W;
    • 1KW and above, the display format is 1000~9999W.
    • 10KW and above, the display format is 10.0~22.0kW
  • Energy: test range: 0~9999kWh
    • Within 10KWh, the display format is 0~9999Wh;
    • 10kWh and above, the display format is 10~9999kWh.
  • Voltage: test range: 80~260V
    • Display format: 80~260V
  • Current: test range: 0~100A
    • Display format: 0.00~99.99A
Package included:
  • 1 x Digital Tester (4in1 Voltmeter/Ammeter/Power Meter/Energy Meter )

Attributes
output ways1

Write a review

Please login or register to review

Multifunction Digital Meter 4in1 Voltmeter/Ammeter/Power Meter/Energy Meter AC 80~260V/100A Digital Tester/Multimeter

  • Brand: Drok
  • Product Code: 200071
  • Availability: In Stock
  • $27.50
  • $11.50
  • Bulk Buy Discounts. Buy more please contact us
    Qty5102030+
    Price$10.93$10.35$9.78$9.20
