It is a Signal Generator/PWM Pulse Frequency Duty Cycle Adjustable Module, Working voltage: DC3.3 ~ 30V; Frequency range: 1Hz ~ 150KHz; Application: motor driver, MCU, PWM dimming speed and other applications.

Parameters:
  • 1. Working voltage: DC3.3 ~ 30V;
  • 2. Frequency range: 1Hz ~ 150KHz;
  • 3. Frequency accuracy: the accuracy in each range is about 2%;
  • 4. Signal load capacity: the output current can be about 5 ~ 30ma;
  • 5. Output amplitude: PWM amplitude equal to the supply voltage;
  • 6. Ambient temperature: -20 °c ~ +70 °c
Application:
  • 1. Used as a square wave signal generator, generate square wave signal for experimental development and use;
  • 2. Used to generate a square wave signal that controls the motor driver;
  • 3. Generate adjustable pulse for MCU use;
  • 4. Generate adjustable pulse, control the relevant circuit (PWM dimming speed and other applications).
Package Includes:
  • 1 x PWM Signal Generator Module
Attributes
input voltage 3.3~30V
output current --
output power --
output voltage --
output ways 1

Write a review

Please login or register to review
$7.25
$16.99
2 or more $6.85
5 or more $6.55
10 or more $6.35
30 or more $5.99
  • Stock: In Stock
  • Model: 2001709005
  • Weight: 0.05kg
  • Dimensions: 10.00cm x 10.00cm x 10.00cm
  • SKU: 2001709005
